ENGINE STYE： 2stroke  air cooling

ENGINE MODEL ：1E34FSA

STANDARD POWER（kw/r/min） ：0.75W/7500r/min

EFFECTIVE CUTTING LENGTH： 600

REDUCTION RATIO ：5.1:1

FORM OF CARBURETOR ：DIAPHRAGM

MAXED FUEL RETIO： 40：1

FUEL TANK CAPACITY(L) ：0.65L

METHOD OF STARTING ：RECOIL STARTING

METHOD OF IGNITION ：Non-contact ignition

WEIGHT(N.W./G.W.)(kg)： 5.4/7.2

PACKING MEASUREMENT(mm) 1110x260x240

1. Add two-stroke special oil (FC grade)

Use 25:1, fill up the petrol to 1L mark, then add two stroke oil to 25:1 mark. Tighten the lid and shake it several times to mix the two oils together.

180°Rotable handle

600mm Alloy blade

magneto limit-speed ignition
